RIA16
6.4.1
When connecting the device, the device DTM is not automatically loaded in FieldCare, i.e. the
device has to be added manually.
Online configuration is not possible with the RIA14/RIA16.
• Firstly, add the Communication DTM "PCP (Readwin) TXU10 / FXA291" to an empty project.
• In the Comm DTM settings, set the baud rate to 2400 baud and select the COM-port used.
• Add the RIA14/16 Version Vx.xx.xx device DTM to the project using the "Add device..."
function.
• To then configure the device itself, follow these Operating Instructions for the device. The
entire Setup menu, i.e. all the parameters listed in these Operating Instructions, can also be
found in the FieldCare Device Setup.
PC Configuration software
 11
In general, it is possible to overwrite parameters with the FieldCare PC software and the
appropriate device DTM even if access protection is active. If access protection by means
of a code should be extended to the software, this function should be activated in the
extended device setup.
Endress+Hauser
Downloaded from
www.Manualslib.com
Connection establishment
Configuration kit USB-Box
USB
Configuring the field indicator via interface adapter
manuals search engine
Operating the field indicator
A0011272-EN
35
