DC Output Operation

Table 1: Output Operation
HL18-_xxxxx
Q1 = D.ON, PNP (≤ 100 mA)
-Axxxxx
Q2 = D.ON, NPN (≤ 100 mA)
Q1 = L.ON, PNP (≤ 100 mA)
-Bxxxxx
Q2 = L.ON, NPN (≤ 100 mA)
8017290.16K9 | SICK
Subject to change without notice
Q2 = switching output 2
L+ = supply voltage (Uv)
L1 = AC supply voltage
M = common
N = AC common
Test = Test input
L.ON = light switching
D.ON = dark switching
NOTE
The sensor outputs may come equipped with an adjustable ON delay or OFF delay. This
is indicated by the model configuration (Hx18-xxxxx_).
ELECTRICAL INSTALLATION
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
