Attachment 5: CV 55, 57, 114, 116, 118 - Special functions A1 - A5
Value
0
1 - 15
+ 64
+ 128
+ 192
Attachment 6: CV 57, 116, 118 – Expanded special functions A2 + A4
Value
16
31
Attachment 7: CV120 – Special function A6
Value
0
1 - 15
Attachment 8: CV121 - RC Servo function
Value
0
1
+ 4
+ 8
Downloaded from www.Manualslib.com
Application
0 = Steady „on"
(Standard operation)
Flashing symmetrical
(Time base 0,25 sec/value)
Short term function (Monoflop)
(Time base 0,25 sec/value)
Asymmetric flashing (1/3 on, 2/3 off)
Asymmetric flashing (2/3 on, 1/3 off)
Application
Inverse coupling with output A1, rsp. A3
Alternate flashing
Charging control of voltage buffer in programming mode
(only A5)
Application
0 = continuous operation (regular switch function)
1 ... 15 = time base for the sound pulse trigger (chuffs)
Application
0 = RC-servo deactivated
1 = RC-servo activated
control level inverted
switch-off after movement
manuals search engine
Note
symmetric flashing
output switches off after time
out
additional value must be added
short „on", long „off"
additional value must be added
short „off", long „on"
additional value must be added
Note
CV57 (A2 with A1)
CV116 (A4 with A3)
Only in CV118
Buffer controlled by A5
Note
1 = slow pulse
15 = fast pulse
Note
