EN
ROTARY LASER
Scan mode
Scan mode allows seeing laser line at long distance. Use remote
control to run this function.
Press button to activate scan mode.
By series press on button
0°, 10°; 45°; 90°; 180°. Press button
counterclockwise, button
To exit scan mode press
Work with laser receiver
Use universal mount included in the set to fix laser receiver on
telescopic levelling rod. Magnets on top and lateral sides of laser
receiver allow fixing it on metal surfaces.
14
CONDTROL Auto RotoLaser
user manual
choose required scan sector –
to move scan sector
- clockwise.
. Rotary head will start rotating.
CONDTROL Auto RotoLaser
EN
ROTARY LASER
1. Press button to turn on laser receiver.
2. Press button to turn on/off sound signal. By default sound
signal is enabled – symbol
3. Press button to select required mode –
1) high accuracy ±1.5mm/40m. Symbol
2) normal accuracy ±2.5mm/40m. Symbol
Expand sensor of laser receiver towards the laser beam and move
laser receiver down/up arrows on the display. For convenience, you
can use the screen on the back of the detector. Down arrow on the
display indicates that laser receiver should be lowered. The up arrow
on the display indicates that laser receiver needs to be lifted up. When
the marks on the sides of laser receiver are at the same level with the
laser line, symbol
sound signal (if sound signal is enabled) – laser receiver is at the same
level with the laser line.
user manual
appears on the display.
appears on the display
appears on the display.
appears on the display and you hear
15
