9. Specifications
Reference pressure sensor model CPT7000-IS
Absolute pressure
EN
Overpressure safety
Process connection
Selectable versions
Sensor data
2)
Accuracy
Resolution
Compensated range
Material
Wetted parts
Internal transmission
fluid
Reference conditions per IEC 61298-1
Atmospheric pressure
Ambient temperature
Air humidity
Position
24
psi 0 ... 15
abs.
0 ... 60
0 ... 300
3 times; < 25 bar
2 times; > 25 bar ... ≤ 600 bar
1.5 times; > 600 bar ... ≤ 1,600 bar
1.3 times; > 1,600 bar ... ≤ 6.000 bar
1.1 times; > 6,000 bar
G ⅜ B
■
G ¼ B
■
G ¼ female
■
G ½ B
■
G ½ male on G ¼ female
■
¼ NPT
■
½ NPT
■
M16 x 1.5 female with sealing
■
cone
M18 x 1.5 male on G ¼ female
■
9/16-18 UNF female F250-C
■
R ½ per ISO7 (DIN 2999)
■
2)
0.025 % of span
5 digits
10 ... 60 °C [50 ... 140 °F]
Stainless steel (with measuring ranges ≤ 25 bar [≤ 360 psi] Elgiloy
addition)
Synthetic oil (only for measuring ranges up to 25 bar [360 psi])
860 hPa < P < 1,060 hPa [12.5 psi < P < 15.4 psi]
18 °C < T < 28 °C, typ. 23 °C
35 % r. h. < H < 95 % r. F. , typ. 55 % r. h.
Hand-held lying face-up
WIKA operating instructions, reference pressure sensor, model CPT7000-IS
0 ... 20 0 ... 30
0 ... 100 0 ... 150
0 ... 500
3 times; < 360 psi
2 times; > 360 psi ... ≤ 8,700 psi
1.5 times; > 8,700 psi ... ≤ 25,000 psi
1.3 times; > 25,000 psi ... ≤ 85,000 psi
1.1 times; > 85,000 psi
G ½ B flush with NBR O-ring
■
G ½ B flush with EPDM O-ring
■
G 1 B flush with NBR O-ring
■
G 1 B flush with EPDM O-ring
■
½ NPT male on ¼ NPT female
■
½ NPT female
■
M20 x 1.5
■
M20 x 1.5 female with sealing
■
cone
0 ... 50
0 ... 200
®
in
