Translation of the original instructions
Function 6
Restore network parameters (LAN):
When the function is accessed, all configurations will be reset to their default
values.
Enable the function by pressing the Programming Button, turn on the
"LED 6", press and hold the button until all the LEDs flash, release it and to
confirm the deletion, press the button until you start flashing all the LEDs.
Exiting from programming mode: Wait 10 seconds for the timeout.

. ACCESSORIES

720119
Enclosure
The enclosure is designed for the Network Controller Device to be installed in
it using the fixing points indicated by the arrows.
202322
Power supply
for boards ENC32 and EDC01.
A DIN rail is provided together with the power supply that can be installed in
the enclosure, using the fixing points indicated in BLACK.
Network Controller
LED
1
2
3
4
5
19
Baud-rate
19200
38400
57600
115200
230400
532227 - Rev.C
