Lan Connections - FAAC ENC32 Handbuch

. LAN CONNECTIONS:

Figure 4 shows an example of a Door Controller-LAN connection.
Use a Cat.5 or 6 shielded (max 100 m) cable to connect the Network Controller
to the same LAN to which the Door Controllers will be connected.
