To insert the resistor at the beginning and end of the 485 branch, use the ju-
J8 or J9
mpers (
See example fig. 6 and 7
End of line
resistor:
NOT INSTAL-
LED

. CONFIGURATION

The settings of the RS485 Bus on the Network Controller are set via the Pro-
gramming Button and displayed by the signalling LEDs.

. LED SIGNALS AND PROGRAMMING FUNCTIONS:

LED 1 indicates that the Network Controller is powered. LEDs 2 to 6 indicate
that the data is being sent to the Door Controller.
Programming:
To access the programming function:
1. Press the button briefly in order to access the programming function.
2. It automatically positions itself on function 1: LED 1 steady.
3. Press the button n times to go to the required function.
4. Pressing it longer accesses the selected function.
(when all the LEDs flash quickly it means that you have pressed it for a suffi-
ciently long time).
Available functions:
Functions
1
view and modify the RS485-1 Baud-rate
2
view and modify the RS485-2 Baud-rate
6
Function 1 and 2
View and modify the RS485 baud-rate. Enable the function by pressing the
Programming Button, turn on the "LED 1 or 2".
LEDs 1 to 5 indicate the set configuration.
To change it, press the button by selecting the desired Baud rate, to confirm
press the button again until all the LEDs start to flash.
Network Controller
) by simply moving the bridge to the position indicated by
6
R
Description
(from 1 to 5)
(from 1 to 5)
restore network parameters
Translation of the original instructions
End of line
resistor:
INSTALLED
18
 7
R
Default
3 - (57600)
3 - (57600)
532227 - Rev.C
EN
R.
