5 LED Display

Status
SD card OK,
receiving data
SD card OK,
time not set *)
Firmware being updated
by SD card
Firmware check sum error
Error: No SD card inserted
Error: SD card error
Error: File system error
Error: Memory card full
LED "Data" (top)
Off, fl ashes green briefl y
every 10 sec.
Red (continuous)
Red (fl ashes very quickly)
Red (fl ashing)
Red (fl ashes)
Red (fl ashes once)
Red (fl ashes twice)
Red (fl ashes 3x)
*) In this status, data is being recorded, but
because the internal clock has not been set,
the data is stored with incorrect time infor-
mation. (See the section "Setting the time
Data
using time.txt").
Power
LED "Power"
(bottom)
Green
Green
Red (fl ashes very quickly)
Red (fl ashing)
Red
Red
Red
Red
