Quick Start

To attach the MultiSync LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate
3. Connect the 15-pin mini D-SUB of the video signal cable to the
4. Connect one end of the power cord to the MultiSync LCD Series
5. Turn on the monitor (Figure D.1) and the computer.
6. To complete the setup of your MultiSync LCD monitor, use the
Refer to the Controls section of this User's Manual for a full description
of these OSM controls.
NOTE:
NOTE:
01c_english
Downloaded from www.Manualslib.com
signal cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD1530V Macintosh cable
adapter to the computer (Figure B.1). Attach the 15-pin mini D-SUB
end of the appropriate signal cable to the MultiSync LCD1530V
Macintosh cable adapter (Figure B.1). Tighten all screws.
Remove connector cover and cable cover on back of monitor
(Figure E.1).
appropriate connector on the back of the monitor (Figure C.1).
NOTE: Incorrect cable connections may result in irregular
operation, damage display quality/components of LCD
module and/or shorten the module's life.
monitor and the other end to the power outlet. Place the video signal
cable and AC power cord under the clips. (Figure C.1).
Replace connector cover and cable cover. (Figure E.1)
NOTE: Adjust the position of the cable under the clips to avoid
damage for cable or monitor.
following OSM controls:
• Auto Adjust Contrast
• Auto Adjust
If you have any problems,please refer to the
Troubleshooting section of this User's Manual.
For easy removal of the cable cover or signal cable, place
the monitor face down. (Figure R.2)
