Teileliste

Nr. Bezeichnung (ENG)
A MAIN FRAME
A1 SENSOR WIRE
A2 CONNECTION SLICE
A3 MOTOR
A3-1 SCREW
A4 DC WIRE
A5 NUT
A6 SENSOR WIRE
A7 SENSOR WIRE HOUSING
A8 SCREW
A9 SCREW M8 x 45
A10 NUT M8
A11 SCREW M6 x 20
A12 NUT M6
A13 END CAP
A14 FIX CUSHIION
A15 WASHER M6
A16 SCREW M5 x 16
A17 WHEEL
A18 NUT M8
A19 SCREW M8 x 45
A20 BELT WHEEL
A21 MAGNETIC
A22 AXLE
A23 SCREW M8 x 25
A24 NUT M8
A25 BUSH
A26 BEARING 6005zz
A27 BUSH
A28 BEARING NUT
A29 BELT
Anz. Nr Bezeichnung (ENG)
1 A30 CRANK
1 A31 FLAT KEY
2 A32 SCREW
1 A33 TURING PLATE
4 A34 PRESSING PIPE
1 A35 BEARING 6003zz
1 A36 C LIP
1 A37 NUT M12
1 A38 WASHER M12
1 A39 AXLE
1 A40 BEARING 6001MRB
1 A41 BUSH
1 A42 FLYWHEEL
1 A43 FLYWHEEL COVER
2 A44 SCREW M4 x 16
2 A45 MAGNETIC HOUSING
2 A49 SCREW M5 x 10
2 A50 FRONT PEDAL SUPPORTING TUBE
2 A51 MAGNETIC
2 A52 SCREW M5 x 8
2 A53 INDUCTION WAND
1 A54 SIDE DECORATION HOUSING SET ( L )
1 A55 SIDE DECORATION HOUSING SET ( R )
1 A56 SCREW
4 A57 BATTERY COVER
4 A58 PUSH ROD BRACKET ( L )
1 A59 PUSH ROD BRACKET ( R )
2 A60 KNOB
1 A61 NYLON SLEEVE
1 A62 BOLT M8 x 20
2 A63 NUT M8
Anz.
2
2
2
2
1
2
1
3
4
1
2
1
1
2
6
1
4
2
4
4
10
2
2
16
4
2
2
2
8
8
8
49
