12. Maintenance

12.1 Care and Cleaning of Your Screen

Follow these steps for cleaning the qLabs
NOTES:
No maintenance is required other than routine cleaning:
• Clean display screen with a clean damp cloth. If necessary, a mild
detergent or disinfectant (such as 5% bleach solution or 70%
isopropyl alcohol) may be used.
• Clean the area around the test strip guide with a swab or a pad that
has been dampened with alcohol or 5% bleach solution.

12.2 Installing/Replacing Batteries

Follow these steps to install/replace the batteries:
1. Turn the qLabs
2. Remove the battery cover screw.
3. Remove the battery cover by pressing down on the battery cover
release, remove the old batteries.
4. Replace with 4 standard AA batteries. Follow the direction for
battery placement (+ and – ends) inside the battery compartment.
5. Fasten the battery cover. Tighten the battery cover screw.
NOTES:
• Turning the qLabs
used will help conserve the battery power.
• Settings for date, time, past test results and reference range will be
saved if batteries are replaced.
• If storing the ElectroMeter for an extended period, completely
remove the batteries before the next use.
Dispose of the batteries in compliance with local regulations.

12.3 Servicing

All servicing and adjustment must be performed by Micropoint
Biotechnologies, Inc.'s service engineers only.
ElectroMeter upside down.
®
ElectroMeter off manually when it is not being
®
27
ElectroMeter:
®
EN
