CORDLESS IMPACT DRIVER
PDSSA 20-Li A1

Introduction

Congratulations on the purchase of your new appli­
ance . You have chosen a high­quality product . The
operating instructions are part of this product . They
contain important information about safety, usage
and disposal . Before using the product, please
familiarise yourself with all operating and safety
instructions . Use the product only as described and
for the range of applications specified . Please also
pass these operating instructions on to any future
owner .

Intended use

This appliance is intended for screwing in and
unscrewing screws as well as for tightening and
loosening nuts . The appliance has clockwise/
anticlockwise rotation, a 1/4" hexagon socket bit
holder and an LED working light . The light on this
appliance is intended to illuminate the immediate
work area of the appliance . The rotary impact
function of the appliance enables the power of the
motor to be converted into uniform rotary impacts .
The impact mechanism comes into effect during
tightening and loosening .
The appliance is designed for use by adults . Young
people under 16 years of age may only use the
appliance under supervision . The manufacturer ac­
cepts no liability for damages caused by improper
use or incorrect operation of the appliance .
Use this product only as described and for the
areas of applications specified . The appliance is
not intended for commercial use . Any other usage
or modification of the appliance is deemed to be
improper and carries a significant risk of accidents .
The manufacturer accepts no responsibility for
damage(s) attributable to misuse .
■ 26
│ GB│MT

Features

Tool holder
Locking sleeve
Bit holder (magnetic)
Rotation direction switch/lock
Belt clip
Battery charge level button
Battery display LED
Battery pack
Release button for battery pack
LED work light
ON/OFF switch / Speed control
Adapter to 1/4" square
Bit holder
High­speed charger
Red charge control LED
Green charge control LED

Package contents

1 cordless impact driver PDSSA 20­Li A1
1 high­speed battery charger PLG 20 A1
1 battery pack PAP 20 A1
1 adapter from hex (1/4") to square
1 1/4" extension (50 mm)
1 belt clip
1 carrying case
1 set of operating instructions

Technical data

Cordless impact driver: PDSSA 20-Li A1
Rated voltage:
Idle speed:
Rated stroke rate:
Max . torque:
Suitable for
metal screws:
Suitable for
wood screws:
Tool holder:
Use only the following battery to operate the
cordless tool: PAP 20 A1
Type:
Rated voltage:
Capacity:
Cells:
20 V (DC)
0–2800 rpm
0–3600 ipm
180 Nm
≤ M8
≤ 8 mm Ø
1/4"
LITHIUM ION
20 V (DC)
2 Ah
5
