CLEANING AND MAINTENANCE

Cleaning the plant
Every season it is necessary to check that the smoke channel
and all the fuel gas discharge conduits are free. Therefore
clean them well. Eventually remove the volatile ash using an
appropriate ash sucker. Consult the area After-sales Centre
regarding the eventual necessary control and maintenance
measures.
6
Cleaning the glass
It is possible to open with doors the hearths panel to clean
the glass.
For this purpose, it is necessary, before opening, to block the
Figure 1: blocked stop lever
hatch in its closing position, by rotating the stop lever (6 fig. 1)
towards the centre.
At this point it is possible to unblock, using the appropriate
6
tool (cold hand) provided, the pallet plate ( 7- fig.3 ) at the
right side of the hatch (rotate by 90°).
Now the door can be opened.
Once cleaned, fix the pallet plate again ( 7 - fig.4 ) and
unblock the stop lever ( 6 - fig.2 ).
Should there only be a slight coat of dirt on the glass., clean it
using a dry cloth whilst it is still warm.
In case of more consistent dirt, EDILKAMIN supplies an
appropriate product "GlassKamin", which can be found
through the authorised retailers.
Figure 2: unblocked stop lever
Never use abrasive products or aggressive
detergents!
Never hot clean.
7
Figure 3: open hatch blocked (rotate the pallet by 90°)
7
Figure 4: closed hatch blocked (rotate the pallet by 90°)
cold hand 7a
