Installation
3. Tighten both lock-nuts on the mounting housing on the solenoid valve.
4. Then carry out a leak test.
5. Screw on the urinal mountings if necessary, depending on the type of urinal.

7.3 Installing the urinal

See separate assembly instructions for the respective urinal for instructions on installation.

7.4 Installing the HF-sensor

The HF sensor is connected to the controller by a plug-in cable.
S. 52
Important
The hosing must be routed parallel to the
wall.
Important
The ceramic and the component to which it is to be attached must be clean, dry, and free
from dust in the bonding area.
The solenoid valve must not stand away
from the wall.
