Installation
1. Break the snap-lugs off the controller.
2. Attach the Terostat tape (supplied) to the housing base of the controller and of the power supply unit.
3. Mount the control unit and mains unit on the ceramics, position
discharge", page 66.
4. Connect the urinal flushing system,
5. Set the urinal controller.
6. Mount siphon onto ceramic.
7. Connect the power supply to the 220V mains using the mains adapter and afterwards mount the urinal to the
wall.
Ensure that the cables are no longer visible. The cables must be neither crushed nor damaged.
8. Before opening the connected water line, you must ensure that the urinal control system has previously been
commissioned for a minimum of 30 seconds (power connection). This applies to the battery and mains
versions.
S. 65
Important
The ceramic and the component to which it is to be attached must be clean, dry, and
free from dust in the bonding area.
Important
If no Bluetooth adapter is mounted:
Before mounting the urinal, connect the urinal flushing system to the power supply
for test purposes, and if necessary adjust the settings on the controller; see separate
operating instructions.
see "Connection diagram", page
see "Housing positions for urinal with vertical
56.
