Bedienungsanleitung mifare-Leser "Accentic" - mit Tastatur Art.-Nr. 026423 - ohne Tastatur Art.-Nr. 026422 mifare DESFire EV1 Leser "Accentic" - mit Tastatur Art.-Nr. 026436.10 - ohne Tastatur Art.-Nr. 026435.10 P30715-03-002-09 Klasse C für ZKA und EMA Änderungen Anerkennungen siehe Kap. 8...
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Inhaltsverzeichnis Seite 1. Allgemeines ..........................3 Datenträger ..........................3 2.1 Einsetzbare Datenträger.......................3 2.2 Richtige Anwendung von Datenträgern.................3 3. Bedien- und Anzeigeelemente....................4 4. Einführung in Bedienabläufe bei ZK und EMA (Leser mit Tastatur) ..........5 5. Anwendung in Zutrittskontrollanlagen..................6 5.1 LED-Anzeige ........................6...
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Allgemeines mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur werden in Zutrittskontroll- und Einbruch- meldeanlagen als berührungslose Leseeinheiten und Bedienteile eingesetzt. Bei Lesern mit Tastatur ist es möglich, eine Kombination von PIN und Karte herzustellen. Je nach verwendetem Controller und dessen Programmierung können über die Tastatur Steuerfunktio-...
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Bedien- und Anzeigeelemente grün Funktion abhängig gelb von der Anwendung rot oder grün Anzeigefeld Scharfschalten Unscharfschalten Funktionstaste Information Zifferntastatur Eingabe löschen Eingabe bestätigen abbrechen Kursiv geschriebene Funktionen nur in Verbindung mit IK3...
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Einführung in Bedienabläufe bei ZK und EMA (nur Leser mit Tastatur) Für die Darstellung eines Bedienablaufs verwenden wir folgende Symbole: ID-Datenträger ins Lesefeld halten 0..9 Eingabe über die Zifferntastatur Info-Taste Funktionstaste Eingabe bestätigen, ok Eingabe löschen, Aktion abbrechen...
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Anwendung in Zutrittskontrollanlagen LED-Anzeige Die LEDs und der Summer werden über Bus gesteuert. Die Definition ihrer Bedeutung wird in der jeweils übergeordneten Software hinterlegt. Am Leser selbst können diesbezüglich keine Ein- stellungen vorgenommen werden.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Anwendung in Einbruchmeldeanlagen LED-Anzeige Im Ruhezustand sind alle LEDs dunkelgesteuert. Bei der Durch- führung einer Funktion ist die Anzeige für ca. 5 Sekunden grün Bereit entsprechend der Funktion angesteuert. Details sind bei den einzel- nen Bedienvorgängen beschrieben.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Bedienung Leser mit Tastatur 6.4.1 Berechtigungsverfahren Je nach geforderter Sicherheit gibt es verschiedene Möglichkeiten, Funktionen aufzurufen. Welche der Möglichkeiten zur Anwendung kommt, legt der Errichter bei der Programmierung der AWE fest. Als "ID" wird ein beliebiger, im System berechtigter Datenträger bezeichnet.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur 6.4.4 Zutrittskontrolle möglich 0..9 PIN eingeben oder Datenträger ins Lesefeld halten 6.4.5 Überfallalarm 6.4.5.1 Überfallcode Mit dem Überfallcode können Sie über die Lesertastatur einen Überfallalarm auslösen. Überfallcode ist mit Ausnahme der letzten Stelle mit der PIN identisch. Bei der letzten Ziffer wird eine 5 dazu addiert.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur 6.4.5.3 Überfallalarm auslösen mit unscharfschalten möglich mit Türfreigabe möglich ohne Türfreigabe Taste "unscharf" betätigen 0..9 Überfallcode eingeben Datenträger ins Lesefeld halten Bei Berechtigung: Überfallalarm wird ausgelöst, Anlage wird unscharfgeschaltet Quittierung: Bei Berechtigung Keine Berechtigung Bereit 5 Sek.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur 6.4.8 Lernmodus für Datenträger Im Lernmodus können Sie auf einfache Weise neue Datenträger berechtigen oder bereits vorhan- dene löschen. Neu "gelernte" Datenträger sind automatisch generalberechtigt . Bei Bedarf an- schließend über die Programmierung PINs / Berechtigungen / Zeitzonen zuweisen.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur 6.4.9 PINs anlegen / ändern Die Art für die Verwendung von PINs hängt von der Programmierung der AWE ab: Jedem Datenträger ist eine individuelle PIN zugeordnet. Mehrere Datenträger können nicht die selbe PIN besitzen.
Bedienungsanleitung mifare/DESFire EV1 Leser "Accentic" mit/ohne Tastatur Bedienung Leser ohne Tastatur 6.5.1 Scharf-/unscharfschalten Datenträger ins Lesefeld halten und wieder entfernen. Grüne LED leuchtet. Gelbe LED leuchtet im Unscharfzustand, im Scharfzustand dunkel. Datenträger erneut ins Lesefeld halten (frühestens nach 1 Sek., spätestens nach 4 Sek.).
Bei starker Verschmutzung können Sie ein mit Wasser angefeuchtetes Tuch benutzen. Verwenden Sie keine Reinigungsmittel, Scheuermittel oder Lösungsmittel wie Spiritus, Alkohol, Benzin o. ä! VdS-Anerkennungen Die mifare Leser „Accentic“ mit/ohne Tastatur sind vom VdS anerkannt und besitzen folgende VdS- Anerkennungs-Nr.: 026422 mifare Leser ohne Tast.
Seite 19
Operating Instructions mifare-reader "Accentic" - with keypad Item no. 026423 - without keypad Item no. 026422 mifare DESFire EV1 reader "Accentic" - with keypad Item no. 026436.10 - without keypad Item no. 026435.10 P30715-03-002-09 Änderungen vorbehalten 2018-04-12...
Seite 20
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Table of Contents Page 1. General............................21 2. D ata carriers ..........................2.1 Possible data carriers ......................21 2.2 Correct use of data carriers....................21 Operating and indication elements ..................2 4. Introduction to operating sequences, ACS and IDS (reader with keypad) ......
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad General The mifare/DESFire EV1 readers "Accentic" are used as contactless readers and operating units in access control and intrusion detection systems. A combination of transponder and PIN can be used for performing functions via the keypad.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Operating and indication elements green Function dependent yellow on the application red oder green Indicator field Disarm Function key Information Numerical keypad Cancel / delete entry Confirm entry Functions written in italics only in conjunction with IK3...
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Introduction to operating sequences , ACS and IDS (reader with keypad) The following symbols are used to represent an operating step: Hold the mifare ID data carrier in the reading field 0..9...
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Application in access control systems LED indication The LEDs and the buzzer are controlled over a bus system. The definition for each is specified in the main software and not at the reader.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Application in intrusion detection systems LED indication In no-load status, all indicators are dark. When a function is being executed, the corresponding indicator is activated for approx. 5 green Ready seconds. Details are described in the individual operating procedures.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Operation, readers with keypad 6.4.1 Authorization process There are different possibilities of calling functions. Which of these possibilities is used, is defined in the programming of the central control unit/EU. ”ID” refers to any data carrier or substitude code, authorized in the system.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.3 Arm/disarm 6.4.3.1 possible Activate the "arm" key 0..9 Enter PIN Hold the data carrier in the reading range System is armed with authorization positive drive Acknowledgement: Fulfilled with authorization No positive drive...
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.4 Access control possible 0..9 Enter PIN Hold the data carrier in the reading range 6.4.5 Hold-up alarm 6.4.5.1 Introduction hold-up alarm can be triggered via the operating unit keypad with a hold-up code.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.5.3 Trigger hold-up alarm with disarming possible with door release possible without door release Activate the "disarm" key 0..9 Enter the hold-up code Hold the data carrier in the reading range With authorization: Hold-up alarm is triggered and the system is disarmed...
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.6 Activate Control functions/macros possible Activate the "F" key 0..9 Enter the function/macro number Confirm with "OK" 0..9 Enter PIN Hold the data carrier in the reading range Quick function: possible Function triggering immediately after pressing the function button ”F”).
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.8 Learning mode for data carriers In learning mode it is simple to authorize new data carriers or delete existing ones. Newly "learned" data carriers automatically receive general authorization . Afterward, use the programming functions to assign PINs / authorizations / time zones.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.4.9 Creating/Changing PINs The manner for using PINs depends on the programming of the evaluation unit: Each data carrier is assigned an individual PIN. Multiple data carriers cannot have the same PIN.
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad Operation, readers without keypad 6.5.1 Arm/disarm Hold data carrier in the reading range and remove. Green LED lights up Yellow LED lights up when disarmed and remains dark when armed. Hold data carrier again in the reading range (at the earliest after 1 sec., at the latest after 4 sec.).
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad 6.5.2 Access control function Hold data carrier in the reading range. Acknowledgement. No authorization or Optical Authorized AC function not activated Acknowledgement with AC function: Ready (green) 5 sec. Disarmed (yellow) Acoustical 2 sec.
Use a cloth moistened by water if heavily soiled. Do not use cleaning agents, abrasives or solvents such as spirits, alcohol or petrol! Hereby, the Novar GmbH declares that the radio equipment mifare reader "Accentic" Item no. 026422, 026423 and mifare DESFire EV1 reader "Accentic" Item no. 026435.10, 026436.10...
