Fronius OPT/i CU Duo Installationsanleitung Seite 42

5
5
Swivel the cooler connection towards the rear
Connect the 200 mm hose
7
7
Secure the hoses in place using cable ties
Arrangement of the coolant hoses before and after installation
42
200 mm
1
1
6
6
3
Position the rubber bushing on the 700 mm hose and
insert the hose into the opening
Connect the 700 mm hose at the front and rear
CU 1400i with optional coolant connections
at the front:
CU 1400i with OPT/i CU Filter mounting /
Duo option installed
2
1
700 mm
