Fronius OPT/i CU Duo Installationsanleitung Seite 40

3
3
Uncut hoses
5
5
Position the rubber bushing on the 750 mm hose and
insert the hose into the opening
Connect the 750 mm hose at the front and rear
7
7
Secure the hoses in place using cable ties
40
750 mm
2
750 mm
1
4
4
(1)
Disconnect the hose from the rear and from the cooler
(1)
6
6
760 mm
1
Swivel the cooler connection towards the front
Connect the 760 mm hose
Position the rubber bushing on the 760 mm hose and
insert the hose into the opening
Connect the 760 mm hose at the front
4
3
760 mm
