Cu 1100I / Fk 5000 With Optional Coolant Connections At The Front: Installing The Opt/I Cu Filter Mount- Ing / Duo - Fronius OPT/i CU Duo Installationsanleitung

CU 1100i / FK
1
1
5000 with option-
al coolant con-
nections at the
front: Installing
the OPT/i CU Fil-
ter mounting /
Duo
Remove the two blanking covers
3
3
Cut the hoses to length
5
5
Swivel the cooler connection towards the rear
Connect the 200 mm hose
36
1
1
670 mm
3
1
1
2
2
Insert the connections from the inside to the outside
Secure the connections with plastic nuts, left = red,
right = black, 21 mm
4
4
3
Disconnect the return hose from the front and from the
cooler
Take the hose out of the opening
6
6
3
1
Position the rubber bushing on the 670 mm hose and
insert the hose into the opening
Connect the 670 mm hose at the front and rear
3
4
black
red
1
3
670 mm
670 mm
2
1
