Note on connect- IMPORTANT! When using the OPT/i CU Filter mounting / Duo option, connect the coolant
ing the coolant fil- filter option to the cooling unit as follows:
ter option -
-
(1)
(2)
Always connect the coolant filter option to the side of the cooling unit with the black
plastic nut
Connect the coolant filter option to the red connection socket
red black
2
Connect the coolant filter option (1) to
1
the red connection socket
Connect the hose (2) supplied with the
2
OPT/i CU Filter mounting / Duo to the
coolant filter
Connect the other end of the hose (2)
3
to the black connection socket
