Instruction Manual - GRAPHITE 58G548 Betriebsanleitung

CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL CAREFULLY AND KEEP IT FOR FUTURE
REFERENCE.
● Use ear protection when operating the rotary hammer drill.
● Use protection measures for respiratory system when operating the rotary hammer drill.
respiratory system illness.
● Use dust extraction systems whenever required by the nature of the work performed.
● Use additional handles supplied with the tool.
CONSTRUCTION AND USE
Rotary hammer drill is a hand-operated power tool with insulation class II. The tool is driven by single-phase commutator
motor with rotational speed reduced with gear transmission. Rotary hammer drill can be used for drilling holes in working
modes: with impact, rotation only, digging channels or surface processing of materials such as concrete, stone, brick
etc. Range of use covers repair and building works, woodworking and any work from the scope of individual, amateur
activities (tinkering).
Use the power tool according to the manufacturer's instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1. SDS Plus chuck
2. Fixing sleeve
3. Depth gauge rod
4. Operation mode switch
5. Direction selector switch
6. Switch
7. Voltage indicator lamp
8. Carbon brush cover
9. Additional handle
10. Fixing lever for depth gauge rod
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Drills
2. Chisels (point and flat)
3. Depth gauge rod
4. Additional handle

INSTRUCTION MANUAL

ROTARY HAMMER DRILL
58G548
DETAILED SAFETY REGULATIONS
Noise hazards may cause hearing loss.
Loss of control may cause operator personal injury.
- 3 pcs 5. Drill chuck + key
- 2 pcs 6. Chuck adapter
- 1 pce 7. Transport case
- 1 pce
11
Dust hazards may cause
- 1 pce
- 1 pce
- 1 pce
