• [P2] Lower return-to-zero push-button. After stopping the chronograph
by pressing the upper control push-button [P1], press the lower push-button
[P2] to reset the counters to zero. This push-button only functions when
the counters are stopped.
• Chronograph second hand: Start and stop by pressing the upper push-button
[P1] Reset to zero by pressing lower push-button [P2].
• Running second hand: Most of the BALL chronographs feature running
seconds in the subdial at 9 o'clock. The Trainmaster Cannonball (CM1052)
and the Engineer Hydrocarbon Magnate Chronograph (CM2098) feature
running seconds at the unusual 3 o'clock position.
• Minute counter: It indicates the minutes elapsed from the start time by
moving forward one unit for each complete revolution of the second hand.
Reset to zero by pressing push-button [P2].
• Hour counter: It indicates the hours elapsed from the start time by moving
forward one unit for each two complete revolutions of the minute counter.
Reset to zero by pressing push-button [P2].
26

6.4 Automatic Chronograph with Moon Phase Display

CALIBER: RR1406
See above instructions for "Automatic Chronograph" with the following
changes.
Position [X]- Running position
Position [0]- Manual winding
Position [1]- Correction of month,
day, and moon
phase display
Position [2]- Time setting with
stop-second
3 push-buttons:
[P1] Push-button at 2 o'clock: Start/stop of chronograph
[P2] Push-button at 4 o'clock: Reset the chronograph
[P3] Pusher at 10 o'clock: Day correction
Chronograph function: First ensure that the crown is in position [X] and
that the chronograph hands are reset to zero.
• 24-hour hand: The red hand displays the time in 24-hour military time
and day/night in the subdial at 9 o'clock.
• Moon Phase display: Subdial at 6 o'clock indicates the phases of the Moon
over a 29 ½ day period. Adjust Moon Phase by turning counterclockwise
