NAMUR Instructions
IN_PV_X X=1;2;3;4;5
OUT_SP_Xn X=1;4
IN_SP_X X=1;2;3;4
START_X X=1;4;5
START_16
STOP_X X=1;4;5
RESET
STATUS_X X=1;4;5
RMP_IN_X X=1;4
RMP_IN_X_y X=1;4
RMP_OUT_X_yn X=1;4
hh:mm:ss
RMP_START_X X=1;4
RMP_STOP_X X=1;4
RMP_PAUSE_X X=1;4
RMP_CONT_X X=1;4
RMP_RESET_X X=1;4
24
Function
Reading the real-value
Setting the rated value to n
Reading the set rated value
Starting the instrument's (remote) function
Activation of the „watchdog" function. If no rated value is enteredIgiven in the next 60 seconds, the heating is
switched off.
Switching off the instrument function. Variables set with OUT_SP_S are maintained. Contains the instruction RMP_STOP.
Switching off the instrument function.
Display of status
1 :A-mode of operation
2 :B-mode of operation
3 :C-mode of operation
0:manual operation without fault
1:Automatic operation Start (without fault)
2:Automatic operation Stop (without fault)
<0: error code: (-1)
-83: wrong parity
-84: unknown instruction
-85: wrong instruction sequence
-86: invalid rated value
-87: not sufficient storage space
Reading the real segment number of ramp. With ramp not started: 0
Reading the accumulated value and the ramp segment duration of ramp segment y.
Setting the accumulated value (n) and the ramp segment duration (hh:mm:ss) for ramp segment y.
Starting the ramp function, beginning with ramp segment No. 1. (Only possible after prior START_X.
After RMP_STOP_X START_X is not necessary.
Switching off ramp function. Rated value = 0. (Ramp is maintained, that means, ramp can be restarted
with RMP_START_X).
Stopping the ramp function. Freezing of real rated value and real ramp segment time.
Continuation of ramp function (After prior RMP_PAUSE_X).
Switching off ramp functions and deleting of all set ramp segments.
Display
(additional)
REMOTE
REMOTE
