Caution!!! It is not allowed to lift and lower the pump with the use of power
supply cable or the float switch. Lifting or lowering the pump with the use
of
cable or float will lead to damage of cables at best, in the worst case scenario, it may
result in an electric shock. Guarantor and manufacturer are exempt from any and all
liability in the event of non-observance of this requirement. Repair of the damaged cable
is possible only upon payment, not under the guarantee.
If there is sand or stones on the bottom of the emptied tank, which may damage the
rotor, or impeller the pump should be immediately suspended on a string at least 0.5
m over the bottom, in order not to suck in the sand or stones.
OPERATION of Multi IP AUTO:
Pumps have automatic functions of multiple modes.
1. When the outlet valve is closed, the pump enters the state of holding pressure and
standby. The pump is in a stop state at this time, but there is pressure in the pipeline.
The pump will automatically open the pump after releasing the pressure of the pipeline
when the outlet valve is opened. 2. When the water is not enough, the pump can not be
pumped out again. The pump will enter the dry operation protection mode. The pump is
stopped at present. The pump will open
only when the power is reconnected. 3. When there is a small leakage in the pipeline,
causing the
machine to open frequently, the pump will enter protection mode. The pump is stopped
at present. The pump will open only when the power is reconnected.
Caution The lubricant used in the pump is oil. Unsealing may lead to oil leakage
which may contaminate the pumped water.
Caution!!! It is not allowed to put hands into the pressure and
suction stub pipes of the working pump!

ELECTRIC INSTALLATION:

The pump should be supplied by 230-240V/50Hz with earthing.
Electric network the pump is to be supplied by should have nominal data compliant
with the data contained on the rating plate of the pump.The plug of the pump must
be connected to a socket with active earthing.
The manufacturer and guarantor are exempt from any liability for damage to
people or things, resulting from the lack of relevant earthing. Yellow and green
conductor of the connection cable is the earthing. Electric network supplying the pump
should be equipped with an installation overcurrent - motor switch, protecting the engine
against overload. In order to the switch to effectively protect the engine against overload,
it should be adjusted to the current of winding given in the data specified on the rating
plate. The pump may work without such protection however, in case of a breakdown
caused by overload, costs of repair shall be borne by the user.
