1. Level sensor
2. Measuring chamber
3. Magnetic display
4. Magnetic switch
5. Mounting flange
6. Guide rod
7. Float
A float (7) connected to a guide rod (6) changes its height in proportion to
the filling level of the tank. At the end of the guide rod is a build in perma-
nent magnet. The magnetic field actuates magnetic display (3) and
switches (4) or level sensors (1) attached to the outside of the indicator
tube (2). Also measuring with guided radar is possible.
These options are factory mounted to customer specifications.
The basic configuration is shown in Fig. 1. Customised versions will have
been implemented as ordered.

2.2 Scope of delivery

Compare the contents of the delivery with the delivery certificate.
6 KSR KUEBLER Operating instructions Top-mounted level gauge UTN-EX
