Connector
10
• 1 x Virtual RAID On CPU Header
• 1 x TPM Header
• 1 x Power LED and Speaker Header
• 2 x RGB LED Headers
* Supports in total up to 12V/3A, 36W LED Strip
• 1 x Voltage Control Header
• 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x CPU Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* The CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed
Control)
• 1 x Chassis Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* The Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CPU_OPT/W_PUMP, CHA_FAN1, CHA_FAN2 and CHA_
FAN3/W_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• 1 x 24 pin ATX Power Connector (Hi-Density Power
Connector) (for Motherboard)
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor) (for Motherboard)
• 1 x 4 pin 12V Power Connector (Hi-Density Power
Connector) (for Motherboard)
• 1 x 6 pin 12V Power Connector (Hi-Density Power
Connector) (for PCIe graphics card)
• 1 x Front Panel Audio Connector (15μ Gold Audio
Connector)
• 1 x Right Angle Front Panel Audio Connector*
* Connect the audio device to either one of the audio
connectors.
• 1 x Thunderbolt AIC Connector (5-pin)
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection)
• 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)
(Supports ESD Protection)
• 1 x Front Panel Type C USB 3.1 Gen2 Header (ASMedia
ASM3142)
