Version 1.0
Published January 2018
Copyright©2018 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com
migliori offerte di Schede Madri
AsRock X370 Pro4
o
Inhaltsverzeichnis
loading

Inhaltszusammenfassung für ASROCK X370 Pro4

  • Seite 21 X370 Pro4...
  • Seite 39: Einleitung

    X370 Pro4 1 Einleitung Vielen Dank, dass Sie sich für das X370 Pro4 von ASRock entschieden haben – ein zuverlässiges Motherboard, das konsequent unter der strengen Qualitätskontrolle von ASRock hergestellt wurde. Es liefert ausgezeichnete Leistung mit robustem Design, das ASRock Streben nach Qualität und Beständigkeit erfüllt.
  • Seite 40: Technische Daten

    • APUs von AMDs A-Serie der 7. Generation unterstützen un- gepufferten DDR4-2400/2133-ECC- und -Non-ECC-Speicher* * Weitere Informationen finden Sie in der Speicherkompatibilitätsliste auf der ASRock-Webseite. (http://www.asrock.com/) * Bitte beachten Sie Seite 22 für die maximal unterstützte Frequenz von DDR4-UDIMM. • Systemspeicher, max. Kapazität: 64GB • 15-μ-Goldkontakt in DIMM-Steckplätze...
  • Seite 41 X370 Pro4 Grafikkarte • Integrierte Grafikkarte der AMD-Radeon -R7/R5-Serie in APU der A-Serie • DirectX 12, Pixel Shader 5.0 • Max. geteilter Speicher: 2GB • Drei Grafikkarten-Ausgangsoptionen: D-Sub, DVI-D und HDMI • Unterstützt drei Monitore • Unterstützt HDMI mit maximaler Auflösung von 4K x 2K (4096 x 2160) bei 24 Hz / (3840 x 2160) bei 30 Hz • Unterstützt DVI-D mit maximaler Auflösung von 1920 x 1200 bei...
  • Seite 42: Anschluss

    Gen3 x2 (16 Gb/s) (mit APU der A-Serie)** • 1 x M.2-Sockel (M2_2), unterstützt 2230/2242/2260/2280/22110-M.2-SATA-III-6,0-Gb/s-Modul** ** Wenn M2_1 belegt ist, wird PCIE4 deaktiviert. ** Unterstützt NVMe-SSD als Bootplatte ** Unterstützt ASRock U.2-Kit Anschluss • 1 x COM-Anschluss-Stiftleiste • 1 x TPM-Stiftleiste • 1 x Betrieb-LED- und Lautsprecher-Stiftleiste • 1 x RGB-LED-Stiftleiste...
  • Seite 43: Funktion

    • FCC, CE • ErP/EuP ready (ErP/EuP ready-Netzteil erforderlich) * Detaillierte Produktinformationen finden Sie auf unserer Webseite: http://www.asrock.com Bitte beachten Sie, dass mit einer Übertaktung, zu der die Anpassung von BIOS-Einstel- lungen, die Anwendung der Untied Overclocking Technology oder die Nutzung von Über- taktungswerkzeugen von Drittanbietern zählen, bestimmte Risiken verbunden sind.
  • Seite 44: Jumpereinstellung

    1.3 Jumpereinstellung Die Abbildung zeigt, wie die Jumper eingestellt werden. Wenn die Jumper-Kappe auf den Kontakten angebracht ist, ist der Jumper „kurzgeschlossen“. Wenn keine Jumper- Kappe auf den Kontakten angebracht ist, ist der Jumper „offen“. Die Abbildung zeigt einen 3-poligen Jumper, dessen Kontakt 1 und Kontakt 2 „kurzgeschlossen“ sind, wenn eine Jumper-Kappe auf diesen 2 Kontakten angebracht ist.
  • Seite 45: Integrierte Stiftleisten Und Anschlüsse

    X370 Pro4 1.4 Integrierte Stiftleisten und Anschlüsse Integrierte Stiftleisten und Anschlüsse sind KEINE Jumper. Bringen Sie KEINE Jumper- Kappen an diesen Stiftleisten und Anschlüssen an. Durch Anbringen von Jumper-Kappen an diesen Stiftleisten und Anschlüssen können Sie das Motherboard dauerhaft beschädi- gen.
  • Seite 46 Betrieb-LED- und Bitte verbinden Sie die Betrieb- SPEAKER DUMMY Lautsprecher-Stiftleiste LED des Gehäuses und den DUMMY (7-polig, SPK_PLED1) Gehäuselautsprecher mit dieser (siehe S. 1, Nr. 15) Stiftleiste. PLED+ PLED+ PLED- Serial-ATA-III-Anschlüsse Diese sechs SATA-III- (SATA3_1: Anschlüsse unterstützen siehe S. 1, Nr. 10) SATA-Datenkabel für interne (SATA3_2: Speichergeräte mit einer Date...
  • Seite 47 X370 Pro4 Audiostiftleiste Diese Stiftleiste dient dem PRESENCE# (Frontblende) Anschließen von Audiogeräten MIC_RET OUT_RET (9-polig, HD_AUDIO1) an der Frontblende. (siehe S. 1, Nr. 24) OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L 1. High Definition Audio unterstützt Anschlusserkennung, der Draht am Gehäuse muss dazu jedoch HDA unterstützt.
  • Seite 48 ATX-Netzanschluss Dieses Motherboard bietet einen 24-poligen ATX-Netzan- (24-polig, ATXPWR1) schluss. Bitte schließen Sie es (siehe S. 1, Nr. 7) zur Nutzung eines 20-poligen ATX-Netzteils entlang Kontakt 1 und Kontakt 13 an. ATX-12-V-Netzanschluss Dieses Motherboard bietet einen 8-poligen ATX-12-V- (8-polig, ATX12V1) Netzanschluss.
  • Seite 49 X370 Pro4 RGB-LED-Stiftleiste RGB-LED-Stiftleiste dient dem (4-polig, RGB_HEAD- Anschließen eines RGB-LED- ER1) Erweiterungskabels, das dem (siehe S. 1, Nr. 6) Nutzer die Auswahl zwischen verschiedenen LED-Lichteffek- ten ermöglicht. Achtung: Installieren Sie das RGB-LED-Kabel niemals falsch herum; andernfalls könnte das Kabel beschädigt werden.
