• In the event of gas escaping from a leaky installation, immediately shut off the gas supply by means of a shut-
-off valve.
• In the event of gas leaking from a leaky gas tank valve: Place a wet blanket on the tank to cool it down and
close the valve on the tank. After cooling down, take the tank outdoors. It is forbidden to reuse damaged
tanks.
• In the case of a few days of downtime, close the main valve on the gas system, or, if using a gas tank, close after each use.
• Do not open the valve on the gas connection or the tank valve without fi rst checking that all gas valves on the unit are
closed.
• Turn off the gas supply on the control panel and close the shut-off valve after use and during cleaning.
2. PURPOSE OF THE DEVICE
The line 700 gas pasta boiler is designed for professional use in catering, bars, restaurants, etc. The appliance is designed for
thermal processing of products (in water). Do not use the pasta boiler as a fryer, grill or frying pan. The pasta boiler should
not be used in any manner other than intended in the manual.
For additional questions, please consult our technical department.

3. TECHNICAL DATA

3.1. Device construction (page 2):
1 - Valve knob, 2 - Safety thermostat, 3 - Solenoid valve cover, 4 - Spark generator cover, 5 - Fittings for refi lling the
chamber, 6 - Spark generator button, 7 - Button fi lling the chamber with water, 8 - Pilot fl ame viewer, 9 - Chamber water
drain valve
3.2. Technical data
CATALOG NUMBER
HEIGHT
WIDTH
DEPTH
GAS POWER
CONTAINER CAPACITY
WEIGHT
VOLTAGE
WATER PROTECTION DEGREE
SUITABLE FOR GAS

4. DEVICE OPERATION

• Before fi rst use, please remove the protective fi lm from the device. Wash the external and internal surfaces of the body
with warm water and a degreasing agent which is used for washing kitchen utensils. Do not use abrasive cleaners and
others which could scratch the surface of the countertop, housing. Only use a damp cloth for washing. After washing the
device, leave it to dry completely, then reconnect to the mains.
• Before use, make sure that the room where the appliance is in is well ventilated, the amount of exhaust air is suffi cient
and is not disturbed. If in doubt, please contact our service. The end user is responsible for cleaning and using the unit in
accordance with the manual. If you have any problems with your device, please contact Stalgast.
• The unit is equipped with an electric igniter (spark generator) to facilitate daily operation - starting the main burner
• Use the pasta boiler in accordance with its intended purpose - for cooking in water products such as pasta, rice. You
must control the appliance during operation.
• The device is equipped with an electromagnetic water valve, which is actuated by a switch on the panel. The valve
allows quick fi lling of the tank with clean water.
• The appliance is equipped with a drain valve located behind the door. Empty the reservoir from water whenever neces-
sary.
• The appliance is equipped with a safety thermostat - if the water boils away from the tank or the appliance is turned on
without water in the tank, the safety thermostat will trigger - it will switch off the gas supply to the main burner. When
the thermostat is on, wait until the thermostat chamber has cooled down, unscrew the red cap on the thermostat and
press the key, refi ll the tank and restart the appliance.
• NOTE - do not cool the chiller down with cold water - this may damage the appliance.
• The manufacturer assumes no liability for any damages caused by incorrect installation,
• improper maintenance and improper use.
• This appliance is intended for industrial use and must be used by trained personnel.
• The device should only be used for the purpose for which it was designed. Any other use is considered misuse.
Rated
Reduced
Table 3.1
- 12 -
9745110
9745130
850 mm
400 mm
700 mm
9,1 kW
3,9 kW
ok. 26 l
54 kg
230V; 50Hz
IP21
G20
G30/G31
