Translation of the original instructions
• The product's manufacturer contributes to the recycling of its
packaging by contributing to a global recycling system.
• This product should be recycled appropriately

PRODUCT IDENTIFICATION

At the back of the product, there is an identification plate on which the CE marking is affixed:
• Name and address of the manufacturer
• Date of manufacture
• Model
• Product Type
• Operating Voltage
This data must be specified for each maintenance intervention, or if spare parts are requested.

PRODUCT SPECIFICATIONS

Power
Operating voltage
Power supply frequency
Heater Frequency
Number of conductors
Container capacity
Cooling liquid
Power supply cable length
Inductor cable length
IP Code
PRODUCT WEIGHT AND DIMENSIONS
Weight (kg)
Dimensions (cm)
DESCRIPTION OF THE MACHINE (FIG I)
1
Heat authorisation illuminated button
2
Main switch
3
Heating power indicator (160LG : 1 kW – 16 kW).
4
Heating power settings or temperature unit button
5
Cooling liquid temperature
6
Inductor or machine fault indicator
7
Cooling circuit warning alarm indicator
8
Machine or cooling circuit thermal protection indicator
9
Inductor change indicator
10
Inductor change mode activation button
11
Lance button : start the heat
12
LED worklight (illuminates the heating point)
13
Lance attachment. For a 36 mm spanner
14
Adapter attachment : 27 mm spanner
POWERDUCTION 110LG / 160LG
110LG
11 kW
25-40 kHz, microprocessor controlled.
7 liters
5 m
4 m
110LG
85 x 58 x 50
340 V - 460 V
50 Hz - 60 Hz
3 + Terre
Special welding liquid coolant
(ref. 052246)
IP 21
80
118 x 80 x 60
EN
160LG
16 kW
30 liters
4 m
6 m
160LG
120
25
