INSTALLATION
WARNING!
Rotating parts can cause injury, take great care.
Place the flux tube in such a way that it does not get folded and that the flux
S
covering is satsfactory. (UP welding)
Filling up with flux. (UP welding)
S
Close the flux valve on the flux container.
S
Loosen the cyclone for the flux recovery unit (if fitted).
S
Fill with flux. NOTE! The flux must be dry. If possible, avoid using agg-
S
lomerated flux outdoors or in humid environment.
Adjust the height of the flux nozzle above the weld to give the correct
S
amount of flux. The flux cover should be thick enough to prevent arc
penetration.
dha3i1ea
- - 6 - -
