Safety Regulations; Layout And Items Supplied - EINHELL L 700 Originalbetriebsanleitung

Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.

1. Safety regulations

Danger!
Read all the instructions for the guide rail
and all the instructions and safety informati-
on for the hand-held circular saw!
Failure to comply with the instructions for the gui-
de rail and the instructions and safety information
for the hand-held circular saw may result in an
electric shock, fi re and/or serious injury.
Keep all the instructions and safety informati-
on in a safe place for future use.

2. Layout and items supplied

2.1 Layout (Fig. 1/2)
1. Guide rail (2x)
2. Guide rail fastener
3. Screw clamp
2.2 Items supplied
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
Anl_L_700_SPK7.indb 8 Anl_L_700_SPK7.indb 8
GB
•
Original operating instructions
•
Safety instructions
3. Assembly
(Fig. 1)
Plug together the two rails supplied.
1. Insert the two pins (a) of the one guide rail (1)
into the slot (b) of the other guide rail.
2. Push the fasteners (2) forward to secure the
two guide rails.
To disassemble, proceed in reverse order.
4. Use
The guide rail is secured to the workpiece in order
to make exact and straight cuts (see point 4.1).
It can also be used to make 45° cuts (see point
4.2).
Danger!
The guide rail (1) can be used only with the TE-
CS 190, TE-CS 165 hand-held circular saw.
Before working with the guide rail, please also
read the operating instructions and the safety in-
formation issued for the hand-held circular saw.
When the fi rst cut is made, a piece of the rubber
lip at the edge of the guide rail will be cut off . This
ensures that the rubber lip rests exactly against
the saw blade. Use a waste piece for this fi rst cut.
4.1 Working with the guide rail (Fig. 2-3)
•
Mark up your workpiece.
•
Position the guide rail (1) so that the edge of
the guide rail (1) rests against the marker line
on the workpiece.
•
Fasten the guide rail (1) with the screw
clamps (3) (see Fig. 2).
•
The nipple on the head of the screw clamp (3)
must sit in the recess at the edge of the guide
rail (1).
•
Place the hand-held circular saw on the guide
rail (1). For 45° cuts see point 4.2.
•
The elevation (c) in the middle of the rail must
coincide with the recess (d) on the hand-held
circular saw (see Fig. 2).
•
Switch on the hand-held circular saw and
move it evenly with little force along the guide
rail.
- 8 -
