Series
QS1L28; QS1T28
QS1L20; QS1T20
QS1L17; QS1T17
QS1L10; QS1T10
QS1L05; QS1T05
QS1L02; QS1T02
Tested in accordance with PNEUROP PN8NTC1.2
Tested in accordance with ISO8662-7
When the life of the tool has expired, it is recommended that the tool be disassembled, degreased and the parts be
4

INSTALLATION

Main Line(s) Inner Ø
to be 3X Size of
Air Tool's Inlet Ø
To Air
System
To Air
Tool
Emergency
L
Shut-Off
Valve
Lubricator Regulator
FRL
Drain Regularly

SPECIFICATIONS

Free speed
rpm
2,800
2,000
1,710
1,000
500
250
SAVE THESE INSTRUCTIONS. DO NOT DESTROY.
separated by material so that they can be recycled.
Branch Line(s) Inner Ø
to be 2X Size of
Air Tool's Inlet Ø
R
F
Filter
Compressor
(Dwg. TPD905-2)
Sound Level dB(A)
Pressure Power
80.9
80.9
80.9
80.9
79.8
80.9
Vibrations Level
m/s
- - - 0.8
- - - 0.8
- - - 0.8
- - - 0.5
- - - 0.8
- - - 0.8
P7440 Edition 10
2
