In this example, it has been 204 days since the device was first
used, and 201 treatments have been successfully completed.
If the daily treatment has already been completed for that day,
and the "push button" is pressed, the treatment record will be
shown followed by the "treatment complete" icon. This is a
reminder that your daily treatment has already been completed
for that day.

Safe Battery Care Information

Do not do any of the following:
• Never heat or throw the batteries in a fire.
• Never charge the batteries.
• Never let the battery ends contact each other or other metal.
Do not let a piece of metal touch both ends of a battery at the
same time.
• Never damage or use damaged batteries.
• Never use batteries other than in their correct position.
• Always keep batteries at room temperature, about 70°F (20°C)
in less than 80% relative humidity and out of direct sunlight.
• Use ONLY the batteries supplied in the carrying case with
SpinaLogic ® .
• The batteries may be replaced only after the display turns off.
Note: Be sure to remove plastic from batteries before replacing
them.
8
Replacing the Battery
The LCD screen will show the following icon when it is time
for new batteries. This picture will be shown at the start of a
treatment or during treatment. The device will turn off after this
picture is displayed.
Never change the batteries when the device is running.
Wait until the device stops operating to change the battery.
The picture in Figure 4, below, shows the correct way to replace
the battery. When replacing the battery, you will see the correct
way to put them in on the inside of the battery compartment. Use
ONLY the batteries supplied with SpinaLogic. They are located in
the carrying case.
Figure 4. Battery Compartment
9
