Figure 2. Putting on the device
1. Place the device around the spot of your back surgery.
(Figure 2, above).
2. Close and secure the belt.
Figure 3. Control Box
3. To start a treatment, press the "push button" next to the liquid
crystal display (LCD) screen (Figure 3, above), hold it down
until it beeps, and then let go.
a. The treatment record will be displayed until it beeps.
b. The 30-minute treatment countdown will begin.
6
LCD
BUTTON
c. After 30 minutes, the "treatment complete" icon will appear
on the LCD screen, the device will beep twice, and it will
automatically shut off.
4. Remove the device and store it until the next day. Please see
the Device Care and Storage section on page 10 for instructions
on the proper storage of the device.

Display Screen

When using the device, the LCD screen will show the time
remaining for your daily treatment. The screen may look
like this:
In this example, there are 29 minutes and 37 seconds remaining
in the 30-minute treatment.

Checking the Treatment Record

You may check your treatment record at any time, except during
your daily 30-minute treatment.
To view the treatment record, press the "push button" and then
let go before it beeps. The LCD screen will look like this:
The number in the upper left-hand corner is the number of days
you have successfully treated. The number in the upper
right-hand corner is the number of days since you first used the
device.
