Specifications
Mixer Section
Controls
Glide Section
Controls
Switches
LFO/Clock Section
Controls
Switches
Sequencer Section
Switches
Arpeggiate Section
Switches
Mode Section
Switches
LED
Filter Section
Controls
Amplifier Section
Controls
Output Section
Controls
LED
OSC A, B and Noise/External input
Rate: 0 to 10
Auto or Normal
Frequency 0 to 10
Sawtooth, Triangle and Pulse
Seq 1, off or Seq 2 (64 note)
Record or Play
Up, off or up/down
Poly or mono
Retrig or normal
Repeat/ext or normal
Drone or off
Gate
Cutoff frequency: 0 to 10
Resonance: 0 to 10
Env amount: 0 to 10
KYBD amount: 0 to 10
Attack: 2.0 mS to 6.5 S
Decay: 2.0 mS to 15 S
Sustain: 0 to 5 V
Release: 2.0 mS to 25 S
Attack: 2.0 mS to 6.5 S
Decay: 2.0 mS to 15 S
Sustain: 0 to 5 V
Release: 2.0 mS to 25 S
Volume: 0 to 10
Master tune -5 to +5
Power
Inputs (TS 3.5 mm)
Mod Wh CV
OSC CV
Gate/Clk
LFO CV
Ext
Cutoff CV
Resonance CV
Outputs (TS 3.5 mm)
LFO out
KB CV
Gate
Mixer
Filter env
Amp env
Phones
Audio out
Power Requirements
External power adaptor
Power consumption
Environmental
Operating temperature range
Physical
Dimensions (H x W x D)
Weight
Shipping weight
Eurorack HP
Quick Start Guide
0 V to +5 V
-5 V to +5 V
More than 2 V (envelope triggers @ 2V)
-5 V to +5 V
Input impedance: 85 Kohm
0 V to +5 V
0 V to +5 V
Triangle: +/-2.5 V, Pulse: +4 V, Sawtooth: +5 V
0 V to +7 V
0 V / +5 V
1/8" TRS, unbalanced max. +20.0 dBu
0 V to +5 V
0 V to +5 V
Signal output
Signal output
12 V DC
8 W maximum
5˚C to 40˚C (41˚F to 104˚F)
95 x 424 x 136 mm (3.7 x 16.7 x 5.4 ")
1.8 kg (4.0 lbs)
2.7 kg (5.9 lbs)
