Operating Instructions

Paper
Die
(Rubber Side Up)
Using any size SureCut
brands of wood dies (AccuCut
1. Place die on Sliding Tray rubber side up, between the lines indicated on the
Tray. With each use, vary placement of dies on the Tray to even out wear on
Roller and Tray. The Sliding Tray can hold up to six Standard Dies (Large,
Small and Tiny), two Double Cut Dies, one Extra Large Die or one Extra
Wide Die.
2. Place material to be cut against the rubber side of the die (Figure C).
3. Push Sliding Tray toward the Roller Cover until the die and material begin to
pass under the Roller Cover. Keep hands away from Roller and dies while in
use.
WARNING
4. When the die and material contact the Roller, begin turning the Bell/Crank
Handle. It might be necessary to lightly push the die or the Sliding Tray to
engage the die in the Rollers. Dies can be passed through the Rollers in
either direction, from the right or from the left.
5. Roll the die and material all the way through, then remove the die and the
perfectly cut shapes, letters and numbers.
* AccuCut is a registered trademark of Tek Industries, Inc.
Figure C
™
and ClearCrop
®
)*
Pinch and cutting hazard. Keep hands,
fingers and clothing away from contact
with Rollers and dies while in use.
6
™
Dies, as well as other
