SwitchView
User Manual
4
Connecting your Computers
2. Power down all computers that will be part of your
SwitchView system.
3. Locate the appropriate cable kit to attach your first
computer to the SwitchView. Now, plug the key-
board cable from the kit into the purple
nector of any available port on your SwitchView.
Ports are labelled A-B on the 2-Port and A-D on
the 4-Port.
Next, plug your mouse cable into the green
nector of the same port.
Plug the video cable into the blue monitor connector.
Plug the remaining cable ends into the matching
ports on your computer. For serial computers,
use only Avocent provided adaptors. Tighten all
thumbscrews.
4. Repeat step 3 for each additional computer to be
attached and then power-up all attached computers.
con-
con-
