Specifications - Avocent SwitchView Bedienungsanleitung

SwitchView
User Manual
2
• Hot-pluggable - new PCs can be added or
removed without powering down the SwitchView
unit or other attached PCs.
• Status LEDs - two LEDs per computer give you
constant readings on the status of your Switch-
View unit.
• Monitor Stand - The SwitchView DT may also
be used as a monitor stand, allowing you to save
valuable desktop space.

Specifications

Mechanical
2 or 4 Port
Height:1.9" (4.83 cm)
Width: 8.1" (20.57 cm)
Depth: 5.0" (12.7 cm)
The SwitchView DT can support a weight of up to 100
pounds (45.36Kg) maximum.
Environmental/Power
Operating Temperature: 41° (5°C) to 104° (40°C)
Storage Temperature: -4° (-20°C) to 122° (50°C)
Optional Power Supply: 6VDC @ 700 mA
Supported Hardware
Computer: IBM PC/AT, PS/2 and 100% compatibles
Video Modes: VGA and SVGA
Maximum Resolution: 1600 x 1200 @ 75 Hz
Peripherals: PS/2 keyboard, PS/2 mouse
Regulatory Compliance Standards
UL 1950, CSA C22.2 No. 950, EN60950
FCC part 15B, EN55022, EN50082, CISPR22, ICES-003
Under certain circumstances it may be necessary to
power the SwitchView with an external power supply. If
this is necessary, the power supply should be a Listed
Direct Plug-In Transformer unit marked "Class 2" or
"L.P.S." and rated at 6 VDC, 700 mA.
DT
Height:1.75" (4.45 cm)
Width: 11.0" (27.94 cm)
Depth: 11.0" (27.94 cm)
