Installation Instructions

WALL MOUNT PLATE PARTS

ITEM DESCRIPTION
10 PLATE, Wall Mount
20 BRACKET, Interface (Right)
30 BRACKET, Interface (Left)
40 SCREW, Phillips, M6 x 12
50 WASHER, Flat, 1/4"
50
100
110
QTY ITEM
1 70
1 80
1 90
4 100
6 110
20
80
90
Figure 1. Wall Mount Plate Parts
DESCRIPTION
SCREW, Self-Tapping
BOLT, Lag, 5/16"
WASHER, 5/16"
ANCHOR, Snap Toggle
SCREW, Phillips Head, 1/4-20 x 1.75"
10
30
40
MSP-DCCLCDS
QTY
2
4
4
4
4
70
3
