OPERATION AND MAINTENANCE

6.1 GETTING STARTED

Read item 5 USAGE CONDITIONS

6.2 SHAFT CONECTION TO POWER UNIT

Power unit is designed to facilitate a quick and safe connection to flexible shaft.

CONNECTION PROCEDURE:

1. Connect the transmission shaft to the square motor connection
2. Screw plastic nut of shaft to aluminium thread of power unit . (Be aware of nut turns left and not
tool is required)
CONNECTION CHOICES :
FLEXIBLE SHAFT LENGTH:
UP TO 6 MTS (TDX 1M, TDX 1,5M, TDX 2M, TDX3M, TDX 4M, TDX5M AND TDX6M)
VIBRATOR DIAMETER :
UP TO 58 MM DIAMETER (AX25, AX32, AX40, AX48 AND AX58)

6.3 ELECTRIC MOTOR CONECTION TO THE SYSTEM

Turn off (position 0) the motor switch before connecting it.

6.4 EARTH CONNECTION

On motors that have plug with earthing, to protect the user from an electrical shock, the motor
should be correctly connected to earth.

6.5 EXTENSION CABLES

On motors that have plug with earthing, always use extension cables with earth wire and its
respective plug with earth in the female and male switches, those which will use the male
switch on the motor.
Do not use damaged or worn out cables.
Avoid heavy loads on top of cables.
To determine the transversal section, follow the following procedure.
DINGO MOTOR - FLEXIBLE SHAFT AND POKERS
TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m
DINGO - AX25, AX32, AX40, AX48, AX58
