4.5 SERVICE

Tool service MUST BE PERFORMED only by qualified repair personnel.
When servicing a tool, USE only identical replacement parts.
FOLLOW instructions in the Maintenance section of this manual.

4.6 SPECIFIC SAFETY RULES

For the proper operation of the motor, MAKE SURE that operators have been instructed in the
proper management of this machine.
The motor SHOULD ONLY BE USED in the specific jobs for with it the help of this manual.
Before connecting the motor to the electrical system, MAKE SURE that the voltage and frequency
coincide with the ones stated in the characteristics equipment plate, located in the top part of the
plastic housing.
DO NOT WORK CLOSE To flammable liquids or in areas exposed to flammable.
ENSURE that all frame screws are tight before starting work.
TO AVOID the flattening of the cable by heavy machinery with could cause breakage.
DO NOT CONNECT THE FLEXIBLE SHAFT TO THE MOTOR WHEN THIS IS WORKING.
DO NOT OPERATE in the motor shaft when this is working and without transmission.
DON NOT WORK with transmission or poker in bad conditions, the motor overheats.
DO NOT WORK with the plastic housing broken.
DO NOT PERMIT untrained personnel to operate the motor or connections.
MAINTAIN free ventilation of air.
The motor plug should not be used to start or stop the equipment.
The electrical feeding cable should not be used to remove the plug from the socket.
MAKE SURE that the electrical cable is with the proper section and functioning properly
Before doing any type of repair, DISCONNECT the motor from the electrical system.
en
When connecting to a generator, MAKE SURE that the out tension and frequency is stable, right,
and has the proper power, (the motor's feeding voltage should not vary more than ± 5% as stated on
the motor's plate).
When finishing the job or when taking a break, the operator SHOULD UNPLUG, disconnect it from
the electrical system, and have it placed in such a way that it should not fall or tip.

4.7 PERSONAL PROTECTIVE EQUIPMENT

Use approved protective equipment. Operators and all other persons in the working
area must wear protective equipment:
Helmet, hearing and eye protection, gloves and boots.
5

USAGE CONDITIONS

For your own safety, as protection for others, and to avoid damage to the equipment, read carefully
the usage recommendations.
1. Before working, to be sure the hose joint nut is fastened to the motor (screwed to left).
2. Be sure the poker is well screwed to the flexible shaft (screwed to left).
3. Do not work with flexible shaft with big bends.
4. Do not overlubricate the shaft.
5. Do not keep working the poker out of the concrete more than 5 minutes.
6. Do not restrict the movement of the poker during the work.
7. Do not stop the poker inside the concrete.
8. Change the wear parts to avoid damage to the internal parts. (Check wearing table for the poker)
9. Do the maintenance with the kinds and quantities of recommended lubricants.
IN ADDITION, LOCAL COUNTRY ESTABLISHED ORDINANCES SHOULD BE RESPECTED.
6
DINGO - AX25, AX32, AX40, AX48, AX58
TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m
DINGO MOTOR - FLEXIBLE SHAFT AND POKERS
