CHARACTERISTICS OF FLEXIBLE SHAFT AND POKERS

The flexible shaft connected to the DINGO power unit sends the movement to an eccentric placed in
the poker, and so it is produced the vibration for the compacting of the concrete.
DIÁMETER
MODEL
(mm)
AX 25 25
AX 32 32
AX 40 40
AX 48 48
AX 58 58
**Test measured with motor Dingo, flexible shaft and poker unloaded K=1,5 at 1,5meters of vibrator.
MODEL
TDX 1m
TDX 1,5 m
TDX 2 m
TDX 3 m
en
TDX 4 m
TDX 5 m
TDX 6 m
Pokers AX25 y AX32 only be connected in the TDXE flexible shaft.
4
DINGO - AX25, AX32, AX40, AX48, AX58
TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m
LENGTH WEIGHT
(mm) (Kg)
285 0,8
366 1, 7
335 2,2
335 3, 2
344 4, 5
*According to ISO5349, flexible shaft to 1m. of the poker and running unload K=2
LENGTH WEIGHT
(m) (Kg)
1,0 3,0 14.250
1,5 3,5 14.000
2,0 4,0 13.750
3,0 5,0 13.500
4,0 6,0 13.000
5,0 7,0 13.000
6,0 8,0 12.000
27mm DIAM. HOSE
CENTRÍFUGAL
FORCE
V.P.M
(Kg)
90 14.000
210 13.750
380 13.500
550 12.500
660 12.000
AX 25 AX 32 AX 40
14.000 13.750
13.750 13.500
13.500 13.250
13.250 13.000
12.750 12.500
12.500 12.000
11.500 11.000
DINGO MOTOR - FLEXIBLE SHAFT AND POKERS
CAPACITY
Acc.
(m³/h)
2
(m/s )*
1,24
UP TO 10
1,41
UP TO 14
1,38
UP TO 17
1,42
UP TO 28
1,67
UP TO 35
AX 48 AX 58
12.750 12.250
12.500 12.000
12.250 11.750
12.000 11.500
11.500 11.000
11.000 10.500
10.500 10.000
NUT TO CONNECT TO THE
MOTOR LEFT THREADS
HOSE END REINFORCEMENT
HEX. DRIVER
LEFT THREADS
Sound Sound
pressure power
(dB A)** (dB A)**
85 93
86 94
88 95
88 95
88 95
