17. Avoid unintentional starting
Don't carry plugged-in tool with finger on switch.
Be sure switch is off when plugging in.
18. Outdoor use extension cords
When tool is used outdoors, use only extension
cords intended for use outdoors and so marked.
19. Stay alert
Watch what you are doing. Use common sense.
Do not operate tool when you are tired.
20. Check damaged parts
Before further use of the tool, a guard or other
part that is damaged should be carefully checked
to determine that it will operate properly and per-
form its intended function. Check for alignment of
moving parts, binding of moving parts, breakage
of parts, mounting, and any other conditions that
may affect its operation. A guard or other part
that is damaged should be properly repaired or
replaced by an authorized service center unless
otherwise indicated elsewhere in this instruction
manual. Have defective switches replaced by
and authorized service center. Do not use tool if
switch does not turn it on and off.
21. Warning
The use of any other accessory or attachment
other than recommended in this operating
instruction or the catalog may present a risk of
personal injury.
22. Have your tool repaired by an expert
This electric appliance is in accordance with the
relevant safety rules. Repairing of electric appli-
ances may be carried out only by experts other-
wise it may cause considerable danger for the
user.

ADDITIONAL SAFETY RULES

1.
Hold the tool firmly.
2.
Secure the workpiece firmly.
3.
Keep hands away from moving parts.
4.
Edges and chips of the workpiece are sharp.
Wear gloves. It is also recommended that you
put on thickly bottomed shoes to prevent
injury.
5.
Do not put the tool on the chips of the work-
piece. Otherwise it can cause damage and
trouble on the tool.
6.
Do not leave the tool running. Operate the
tool only when hand-held.
7.
Always be sure you have a firm footing. Be
sure no one is below when using the tool in
high locations.
8.
Do not touch the blade or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
9.
Avoid cutting electrical wires. It can cause
serious accident by electric shock.
SAVE THESE INSTRUCTIONS.
OPERATING INSTRUCTIONS
Blade inspection
Before using the tool, check the blades for wear. Dull,
worn blades will result in poor shearing action, and
the service life of the tool will be shortened.
The service life of the blades varies in terms of the
materials to be cut and the fixed blade clearance.
Roughly speaking, a blade can cut about 500 m of
3.2 mm mild steel with one cutting edge (total
2,000 m with four cutting edges).
Rotating or replacing blades
Important:
Always be sure that the tool is switched off and
unplugged before rotating or replacing the blades.
Both the upper and lower blades have four cutting
edges. When the cutting edge becomes dull, rotate
both the upper and the lower blades 90° to expose
new cutting edges. When all four edges are dull on
both the upper and lower blades, replace both blades
with new ones. Each time blades are rotated or
replaced, proceed as follows.
Remove the blade securing bolts with the hex wrench
provided and then rotate or replace the blades.
(Fig. 1)
Install the upper blade and tighten the upper blade
securing bolt with the hex wrench. Press up on the
upper blade while tightening it. (Fig. 2)
After securing the upper blade, be sure that there is
no gap left between the upper blade and the bevelled
surface of the blade holder. (Fig. 3)
Then install the lower blade like the upper blade while
adjusting the clearance between the upper blade and
lower blades. When performing this adjustment, the
ENB011-2
upper blade should be in the lowered position. First,
semi- tighten the lower blade securing bolt, then
insert the thickness gauge for the desired clearance.
The cutting thickness is indicated on the thickness
gauge so the combinations shown in the table below
should be used. Work the lower blade positioning bolt
on the yoke until the clearance is such that the thick-
ness gauge moves only with some difficulty. Then
firmly tighten the lower blade securing bolt. Finally,
tighten the hex nut to secure the lower blade position-
ing bolt. (Fig. 4 & 5)
Thickness gauge combinations
Material thickness
Thickness gauge
combinations
2.3 mm
2.5 mm
3.2 mm
1.0 + 1.5 1.0 + 1.5 1.5 + 2.0
