4

Operation

GB
4.1 Placing the camera and receiver
Practical experience has shown that an optimum recep-
tion is achieved when placing the units at a height of
minimum 1.5 m to 2 m above the ground. Prior to the final
mounting, a trial run is recommended as the transmis-
sion quality can substantially be changed by displacing
the camera and the receiver by a few centimetres only.
If required, the camera can be mounted at a suitable
place with the supplied support (8). After releasing the
corresponding nuts, the camera can be inclined and
moved.
4.2 Connections
1) Connect the receiver via the supplied cable with
phono connectors to the monitor:
the jack AUDIO (17) to the audio input
the jack VIDEO (18) to the video input
2) Connect one of the supplied antennas (11) to the jack
ANT (12). Alternatively, with insufficient receiving
quality, it is also possible to use a 2.4 GHz directional
antenna with corresponding gain, e. g. an antenna of
the DX series from MONACOR.
3) Connect the plug (19) of the supplied smaller 12 V
power supply unit to the jack DC12V (16) and the
power supply unit to a mains socket (230 V~/50 Hz).
4) Connect the second antenna (7) to the SMA jack (6)
of the camera.
5) Connect the plug (10) of the supplied larger 12 V
power supply unit to the inline jack (9) of the camera
10
and the power supply unit to a mains socket (230 V~/
50 Hz). Thus, the camera is in operation. After use
disconnect the power supply unit from the socket for
switching off. In case of outdoor mounting, the low
voltage inline jack (9) and the low voltage plug (10)
must be made weather-resistant.
The different plugs (10, 19) of the two power sup-
ply units ensure that the camera and receiver are not
mixed up, and thus an overload of the power supply
units is prevented.
4.3 Channel selection
The camera is factory-set to channel 1. After switching on
the receiver with the POWER switch (15), the channel 1
is likewise selected: The LED CH1 (13) lights up. If this
channel is interference-free and if no second camera is
operated at the same time, it is not necessary to pay
attention to the following information.
The wireless transmission is made in the 2.4 GHz range
which has been divided into four channels for the series
of units AV-4xxSET. Two wireless cameras can be opera-
ted at the same time, e. g. to monitor two rooms. For this
purpose always one channel between the two transmis-
sion channels must remain free, so that they do not inter-
fere with each other. The following channel combinations
are possible:
channel 1 and channel 3 or
channel 1 and channel 4 or
channel 2 and channel 4
1) To adjust another transmitting channel, slide the
sunshield (4) backwards and screw off the front
