Promise Technology VessJBOD 1730 Kurzanleitung Seite 9

Figure 8. Rack mount assembly diagram
Rack front post
Inside of post
This completes rack mounting. Go to "Task 3: Installing Disk Drives" on page 10.
Locating pins (2 on each end)
Rail attaching screws
(not included)
Front rail
Rail adjustment screw
(center, outside of rail)
Task 2: Mounting VessJBOD in a Rack
Flange
Support
Rear rail
9
Rack back post
Inside of post
