Figure 13.Data connections with SuperTrak
SAS port on
RAID controller
Host PC or Server
VessJBOD 1830
VessJBOD 1830+
VessJBOD 1730
This completes data and management connections. Go to "Task 5: Setting Up
Serial Cable Connections" on page 16.
Task 4: Making Data and Management Connections
SAS IN port
SAS IN port
SAS IN port
15
SuperTrak RAID
Controller card
SAS OUT port
SAS OUT port
