Figure 12.Data and management connections with VessRAID
Host PCs or
Servers
Network
Switch
Management
Port
VessRAID 1830s+
VessJBOD 1830+
VessJBOD 1730
This completes data and management connections. Go to "Task 5: Setting Up
Serial Cable Connections" on page 16.
Task 4: Making Data and Management Connections
SAS IN port
SAS IN port
13
SAS HBA
cards
SAS IN ports
Expansion
SAS port
SAS OUT port
