Installer instructions: jumper and dip-switch settings
The installer can change the factory settings on the PCB (Fig. 17) as follows:
Jumper setting (fig 18)
For all the models the motor has two operating speeds: V1 and V2. For models 100 VK N and 100 VK NF by
appropriately setting the jumpers as described in the following table it is possible to determine which will be
the maximum and minimum speed between V1 and V2. The timer will always act on V1.
Speed
V1
V2
Dip-switch setting (fig. 19)
For models 100 VK N and 100 VK NF the PCB has 6 dip-switches.
N.B. Before making any changes to the dip-switches, disconnect the electric power supply.
The following tables summarise the possible settings for the dip-switches of the two models:
100 VK N
0 sec.
OFF
45 sec.
ON
T
A
90 sec.
OFF
120 sec.
ON
6 min.
--
10 min.
--
T
B
15 min.
--
21 min.
--
0 hr.
--
8 hr.
--
T
C
12 hr.
--
24 hr.
--
Int. 1
Int. 2
OFF
OFF
ON
ON
--
--
--
--
--
--
--
--
Jumper
Position A
MIN speed
MAX speed
DIP switch
Int. 3
Int. 4
--
--
--
--
--
--
--
--
OFF
OFF
ON
OFF
OFF
ON
ON
ON
--
--
--
--
--
--
--
--
Position B
MAX speed
MIN speed
Int. 5
Int. 6
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
OFF
OFF
ON
OFF
OFF
ON
ON
ON
37
