Items supplied

The fan unit is enclosed in a plastic cylinder incorporated in the motor carrier, which can be entirely
accommodated in the destination pipe and whose short length makes it perfectly compatible with installation
near elbow bends (90°), typical of pipe fittings.
The main parts of the appliance are:
• Motor carrier and front panel, made of ABS thermoplastic, impact resistant and anti-UV resin;
• Centrifugal rotor made of PP resin, designed for high performance, low power consumption and low noise
emissions;
• Motor with shielded poles, equipped with ball bearings and fitted with a thermal fuse;
• PCB, different depending on the model.

Installation

Figg 2 ÷ 14.
NOTE
In any position of the appliance, the backdraught shutter must always be placed in upright/vertical position
(see pictures 9,10).
NOTE
In case the backdraught shutter should be removed from its original location and/or disassembled into its
components it will be possible to reposition it back as shown in picture 10a, 10b.
